Product features:
The air way connection adopts fast connecting flange structure, which is quick and convenient to load and unload, and can be completed with only one clamp.
The furnace is divided into upper and lower parts, and the upper part of the furnace can be turned back 100 °, which is convenient for taking and placing and observing materials.
The furnace is made of polycrystalline mullite fiber vacuum adsorption, and the temperature field is uniform and energy saving is more than 50%.
Patented air diversion and heat insulation technology ensures the service life and constant temperature effect of the parts in the box.
When the temperature of the furnace surface and electrical part reaches 40 degrees, the exhaust fan runs automatically, and continues to run after the test, which can effectively protect the temperature rise of the furnace surface less than 50 degrees.
The furnace door opens automatic power off, overtemperature protection function and leakage protection function to ensure the safety of use.
Imported program temperature control system, 4 curves, programmable 40-segment program temperature control.
The circuit adopts continuous heating output mode, double circuit power supply, strong and weak electricity separate wiring to improve the stability of the system.
The heating module uses DC signal to adjust the output power, which avoids the interference of induction electricity to the control signal.
The operation button is made of low-voltage metal button, with its own status indicator, which makes the operation safe and intuitive.
The upper and lower furnace body is connected by aviation plug, which is safe, reliable and convenient.
The gas circuit assembly is made of food grade 316 stainless steel, which has corrosion resistance, atmospheric corrosion resistance and high temperature resistance, and is non-magnetic.

TF12P50/TF12P60/TF12P80/TF12P100/TF12P50S/TF12P60S/TF12P80S/TF12P100S

TF12P50/TF12T50  TF12P60/TF12T60  TF12P80/TF12T80  TF12P100/TF12T100  TF12P50S/TF12T50S  TF12P60S/TF12T60S  TF12P80S/TF12T80S  TF12P100S/TF12T100S

TF16P50/TF16P60/TF16P80/TF16P100/TF16P60S/TF16P80S/TF16P100S

TF16T50/TF16T60/TF16T80/TF16T100/TF16T60S/TF16T80S/TF16T100S

TF16P50  TF16P60  TF16P80  TF16P100  TF16P60S  TF16P80S  TF16P100S  TF16T50  TF16T60  TF16T80  TF16T100  TF16P60S  TF16T80S  TF16T100S

DK-98-II  DL-I-15  Single couplet1KW  Single couplet2KW  Duplex  ，Quadruple couplet，Six couplets

TF14P40/TF14T40/TF14P50/TF14T50/TF14P60/TF14T60/TF14P80/TF14T80/

TF14P40  TF14P50  TF14P60  TF14P80  TF14T40  TF14T50  TF14T60  TF14T80

SX- (2.5/4/8/12)-10 SX-(2.5/5/10)-12 SRJX-(2/2.5/4/5/8)-13

SX-2.5-10  SX-4-10 SX-8-10  SX-12-10  SX-2.5-12  SX-5-12  SX-10-12  SRJX-4-13  SRJX-5-13  SRJX-8-13  SRJX-2-13  SRJX-2.5-13
